Lytra Nova Downlight

Recessed solution for premium class corridors and office lighting with high-efficient LED modules, dedicated for installation into plasterboard ceilings or any other type of false ceilings. Functional design in combination with high light output.

Luminaire housing made of 0,6mm sheet steel, white powder coated finish (RAL9003). Upper part of the luminaire made of aluminium plate, that serves as passive heat sink for employed LED modules. Increased protection of the optical part against dirt (IP40). Dark Light concept with UGR <16.

OPTICAL SYSTEM

Discreet low glare solution combines square reflector elements and internal lenses for glare-free light. Optical system is made of PC/ABS, available in piano black or white finish. Internal lenses made of PMMA. Suitable for VDU workstations: luminance of light emitting area is in accordance with EN 12464-1.

ELECTRICAL EQUIPMENT

• linear LED modules fixed inside aluminium housing
• integrated electronic LED driver
• terminal block with strain relief, max. 2,5mm2

OPTIONAL EQUIPMENT

• wiring with emergency unit (1 or 3h)

• wiring with dimmable electronic controlgear(DSI,DALI) • various colour finishing

• fast connectors(Wieland,Wago,Isodom)
